FIXED WRAPPING MACHINE
Semiautomática F-2200.
The Wrapping Machine within everyone's reach: F-2200
The F-2200 automatic fixed machine is a rotary arm pallet wrapping machine. It is a machine designed and manufactured by us in Spain.
Its installation does not require any previous work. The auxiliary column (optional) allows the stretch wrapping machine to be installed anywhere in the warehouse.
–
It is specially designed for WaaS Service and it uses our high-performance stretch films, with greater load retention capacity (memory) and environmental improvement due to a reduction (-50%) of waste.
It allows wrapping up to 40 pallets per hour of any type of load, including unstable pallets, picking pallets, pallets with different heights, etc. It has a touch display that can be used to program numerous wrapping cycles and different wrapping options.
The machine is equipped with a laser device that detects the presence of people near the turning radius of the wrapping arm and stops it automatically to avoid impacts.
The stretch wrapping machine is permanently connected remotely to our machine management center, which allows us to prevent breakdowns, detect possible problems in advance, etc. The WaaS Service includes a preventive maintenance plan for the machine, on-site assistance within 24/48 hours and instant remote assistance throughout Spain and Portugal.
.svg)
Remote-connected wrapping machines.
- Video demo
FIXED WRAPPING MACHINE
Advantages.
The Wrapping Machine within everyone's reach: F-2200.
No construction work required: thanks to its double fixing bracket and the auxiliary column (optional), it can be installed anywhere in the warehouse.
Cost saving: nuestros films de alto rendimiento especialmente desarrollados para el Servicio SIEplus garantizan un demostrable ahorro económico.
Waste reduction: the wrapping machine optimizes and reduces the use of stretch film (approx. 50%), and guarantees an optimal securing of the wrapped goods during transport.
Safety: the machine is equipped with a laser device that detects the presence of people or objects near the turning radius of the wrapping arm and stops it automatically to avoid impacts.
Respuesta técnica inmediata/rápida: the stretch wrapping machine is remotely connected to our machine control center.
Technical data.
Power supply voltage
Monofásico 230 VC 50 Hz
Installed power
2.3KW
Maximum rotation speed
23 rpm
Carriage up/down speed
0,074 m/s
Weight
285 Kg
Machine height
2.590 mm
Useful wrapping height
2.200 mm
Max. pallet dimensions
1.2000mm x 1.200mm
Minimum perimeter zone
2.900mm x 2.900mm
Production according to cycles
20-40 pallets / hour
